116
- Troubleshooting the WLAN
WLAN Specifications
* “Wi-Fi based” indicates that the interconnectivity test of the organization which guarantees the interconnectivity of wireless LAN (Wi-Fi Alliance) has
been passed.
** The communication ranges shown above will increase or decrease depending on factors such as number of walls, reflective material, or interference
from external RF sources.
*** Encryption with network key (WEP) is performed using the above number of bits, however, users can set 40 bits/104 bits after subtracting the fixed
length of 24 bits.
**** Depending on practical environments, the allowable number of computers to be connected may be decreased.
Item Specification
Type of network Integrated Intel Centrino Wireless-N 2200 device conforms to 802.11b/g, and 802.11n, Wi-Fi
based*.
Transfer rate (Automatic switching) 150 Mbps (IEEE802.11n) maximum data rate.
Active frequency
• 802.11n: 2.4 GHz
• 802.11b/g: 2400~2473 MHz
Number of channels
• 802.11b/g: 11 channels, 3 non-overlapping channels
• 802.11n:
2.4 GHz - 3 non-overlapping channels when Channel Bonding is not used; 2 non-overlapping
channels when Channel Bonding is used.
Typical operating distances**
• 802.11b: 100 ft. (30 m) @ 11 Mbps; 300 ft. (91 m) @ 1 Mbps
• 802.11g: 100 ft. (30 m) @ 54 Mbps; 300 ft. (91 m) @ 1 Mbps
• 802.11n: Estimated double the operating distance of 802.11g and 802.11a in their respective
frequencies.
Security
• Encryption Types - WEP, TKIP, AES***, WPA 1.0, WPA2,CCX compliant
Encryption Key lengths Supported: 64 bits and 128 bits 802.1x/EAP
Maximum recommended number of
computers to be connected over wireless LAN
(during ad hoc connection)
10 units or less ****
