56
- Memory Upgrade Module
Removing a Memory Upgrade Module
1 Perform steps 1 through 4 of Installing a Memory Upgrade Module.
2 Pull the clips sideways away from each side of the memory upgrade module at the same time.
3 While holding the clips out, remove the module from the slot by lifting it up and pulling it away from your
notebook. (Figure 31)
4 Store the memory upgrade module in a static guarded sleeve.
5 Replace the cover and reinstall the screws.
Figure 28. Removing the Memory Cover Screws Figure 29. Opening the Memory Compartment
THE MEMORY UPGRADE MODULE IS NOT SOMETHING YOU ROUTINELY REMOVE FROM YOUR NOTEBOOK. ONCE IT IS INSTALLED, YOU SHOULD LEAVE IT
IN PLACE UNLESS YOU WANT TO CHANGE SYSTEM MEMORY CAPACITY.
