Fujitsu P34-9 UE User Manual

Operation
► Press the but ton to call up t he mai
n m enu.
► Press the
button twice and then to switch to the OSD submenu.
► Press the
/ button to mark a func
tion in the submenu.
► Press the
/ or / button to make the desired setting.
► Press the
button to save the set tings and return to the ma in m enu.
Function Description
Language
Selecting the language for the OSD menu
With this function you select the language for the OSD menu.
► Press the
button to arrive at the choice of language.
► Press the
/ button to select the desired language.
► Press the
buttontocon
firm the language selected or
to leave the
language selection op
tion without making any changes.
Timeout
Setting the display duration of the OSD menu
With this function you can select a v alue from 10 t o 120 seconds.
If the set time expires without a setting being made, the OSD menu is
automatically hidden.
Where applicable, settings that must be confirmed with the
button a re
thereby lost.
Rotation
Set the orientation of the OSD menu
This function allows the orientation o f the OSD menu to be rotated. This
makes it easier to read the OSD menu while the pivot function is being used.
Off = OSD menu will not be rotated
On = OSD menu will be turned through 90°.
Auto = orientation of the OSD menu will automatically be matched to the
orientation of the monitor.
The Auto setting only appears on m odels with a rotation sensor.
Fujitsu 27

Fujitsu P34-9 UE Specifications

General

Pixel pitch	0.2325 x 0.2325 mm
Display diagonal	34.1 \
Display technology	LED
Native aspect ratio	21:9
Maximum refresh rate	- Hz
Viewable size, vertical	335 mm
Contrast ratio (typical)	1000:1
Display number of colors	1.073 billion colors
Viewable size, horizontal	800 mm
Digital vertical frequency	28 - 102 Hz
Digital horizontal frequency	30 - 160 kHz
Display brightness (typical)	400 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1440 x 900 (WXGA+), 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 2560 x 1080, 2560 x 1440
AMD FreeSync	Yes
Number of speakers	2
Product color	Gray
Market positioning	-
Sustainability certificates	EPEAT Gold, ENERGY STAR
DisplayPort version	1.2
USB Type-A downstream ports quantity	4
USB Type-C downstream ports quantity	1
Tilt angle range	-4 - 34 °
Cable lock slot type	Kensington
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (off)	0.24 W
Power consumption (standby)	- W
Power consumption (typical)	33.34 W
Power consumption (PowerSave)	0.26 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	10 - 85 %
Package depth	325 mm
Package width	935 mm
Package height	500 mm
Package weight	12650 g
Cables included	AC, DisplayPort, HDMI, USB Type-A to USB Type-B, USB Type-C to USB Type-C
DisplayPort cable length	1.8 m
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth (with stand)	275 mm
Height (with stand)	390.3 mm
Weight (with stand)	8950 g
Depth (without stand)	109.39 mm
Width (without stand)	814.82 mm
Height (without stand)	372.8 mm
Weight (without stand)	6220 g
