Fujitsu PRIMERGY TX2540 M1 User Manual

68 Operating Manual TX2540 M1
Starting up and operation
6.2.1.2 Control elements
Lock (only floorstand model)
The server can be locked to prevent access to the drives.
On/Off button
When the system is switched off, it can be switched on again by
pressing the On/Off button.
When the system is operating, pressing the On/Off button will
switch off the system.
V CAUTION!
Risk of loss of data!
I The On/Off button does not disconnect the server from the
mains voltage. To disconnect from the mains completely,
remove the power plug(s).
NMI NMI button
V CAUTION!
Do not press! Risk of loss of data! The NMI button may only
be used by service personnel.
RST Reset button
Pressing the reset button reboots the system.
V CAUTION!
Risk of loss of data!
ID ID button
ID LED lights up (blue) on the front and on the rear of the server
when the ID button is pressed. Both ID indicators are
synchronized.

Fujitsu PRIMERGY TX2540 M1 Specifications

General

Processor socket	-
Intel Xeon series	E5-2400
Built-in processor	No
Motherboard chipset	Intel® C602
Number of processors supported	2
Number of DIMM slots	12
Supported memory types	DDR3-SDRAM
Maximum internal memory	192 GB
RAID levels	0, 1, 10
Hot-swap HDD bays	Yes
Storage drive sizes supported	3.5 \
Number of storage drives supported	4
Supported storage drive interfaces	Serial ATA, Serial Attached SCSI (SAS)
LAN controller	Intel I210
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
USB 2.0 ports quantity	6
Chassis type	Tower
Product color	Black
