Fujitsu PRIMERGY TX2540 M1 User Manual

TX2540 M1 Operating Manual
Contents
1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
1.1 Documentation overview . . . . . . . . . . . . . . . . . . . 12
1.2 Concept and target groups for this manual . . . . . . . . . 13
1.3 Notational conventions . . . . . . . . . . . . . . . . . . . . 13
2 Functional overview . . . . . . . . . . . . . . . . . . . . . . 15
2.1 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
2.2 Server specification . . . . . . . . . . . . . . . . . . . . . . 26
3 Installation steps, overview . . . . . . . . . . . . . . . . . . 35
4 Important information . . . . . . . . . . . . . . . . . . . . . 37
4.1 Safety instructions . . . . . . . . . . . . . . . . . . . . . . . 37
4.2 CE conformity . . . . . . . . . . . . . . . . . . . . . . . . . 45
4.3 FCC Class A Compliance Statement . . . . . . . . . . . . . 46
4.4 Transporting the server . . . . . . . . . . . . . . . . . . . . 47
4.5 Notes on installing the server in the rack . . . . . . . . . . . 48
4.6 Environmental protection . . . . . . . . . . . . . . . . . . . 49
5 Hardware installation . . . . . . . . . . . . . . . . . . . . . . 51
5.1 Unpacking the server . . . . . . . . . . . . . . . . . . . . . 52
5.2 Setting up the floorstand model . . . . . . . . . . . . . . . . 53
5.2.1 Mounting the anti-tilt bracket . . . . . . . . . . . . . . . . . . . 53
5.3 Installing/removing the rack model . . . . . . . . . . . . . . 54
5.4 Connecting devices to the server . . . . . . . . . . . . . . . 56

Fujitsu PRIMERGY TX2540 M1 Specifications

General

Processor socket	-
Intel Xeon series	E5-2400
Built-in processor	No
Motherboard chipset	Intel® C602
Number of processors supported	2
Number of DIMM slots	12
Supported memory types	DDR3-SDRAM
Maximum internal memory	192 GB
RAID levels	0, 1, 10
Hot-swap HDD bays	Yes
Storage drive sizes supported	3.5 \
Number of storage drives supported	4
Supported storage drive interfaces	Serial ATA, Serial Attached SCSI (SAS)
LAN controller	Intel I210
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
USB 2.0 ports quantity	6
Chassis type	Tower
Product color	Black
