Furuno DS-8500 - Distributor Unit Wiring

2. WIRING
2-5
2.4 Distributor Unit
2.4.1 Required tools
The following item should be prepared in advance for this installation locally.
2.4.2 How to fabricate the cables
Note:
Make sure that the cover does not contact any connected cables when you
close the cover.
TTYCSLA-4/-1 DPYC(Y)-1.5 for Navigation equipment and display unit,
transceiver unit
TTYCY-4S for transceiver unit (used with DS-80)
Item Qty Remarks
Cable tie 61 Equivalent of Convex CV-150B (125 × 4.9 mm)
Drain wire
Drain wire
Pass a heat shrinkable tube
(local supply) onto the drain wire.
Vinyl tape
6
330330
7575
255255
Power line
䠄
For transceiver
unit only
䠅
Power line
䠄
For transceiver
unit only
䠅
Inner sheathInner sheath
Armor
Attach the crimp-on
lug to power line.
Vinyl tape
Pass a heat shrinkable tube
(local supply) onto the drain wire.
330330
7575
255255
6
Armor
Inner sheathInner sheath
Shield lineShield line
Power line
䠄
For transceiver
unit only
䠅
Power line
䠄
For transceiver
unit only
䠅
Attach the crimp-on
lug to power line.
