APPENDEX
AP-10
Interface Documentation
"DATA1" Port
IEC 61162-1/NMEA 0183 Ver. 1.5 Output
• Output Schematic Diagram (Talker)
1
2
6
4
3
8
DATA 1
J5
TD-A
TD-B
FL4
FL5
MJ-A6SRMD
20P8192
U25
SN75ALS172
• Output Drive Capability
Max. 10mA
NMEA 0183 Input
1
J5
2
3
4
5
6
RD-H
RD-C
1
3
4
5
FL7
DATA 1
20P8192
MJ-A6SRMD
R123
390
FL6
CR15
1SS272
PC-400
U26
+3.3V
R130
2.2K
JP1
R182
100
