6-1
6. SETTING UP VARIOUS DISPLAYS
6.1 The Data Display
The user may select what data to display in
four locations on the data display.
JAN 12, 2009 23:59'59" U
12 23.456' N
123 23.456' E
Position
RNG
31.23
NM
SOG
12.3
kn
BRG
223.4
COG
123.4
TO : 001
MARINE
POINT1
NEXT : 002
MARINE
POINT2
User-defined
display data #1
User-defined
display data #2
User-defined
display data #4
User-defined
display data #3
User-defined
display window
W84
D3D 100m
* * SAFE
Figure 6-1 Data display
The data the user may display are;
• Altitude (ALT)*
• Average course (AVR COG)
• Average speed (AVR SOG)
• Course (COG)
• Course error (dCOG)
• Cross track error (XTE)
• Depth (WAT DPTH)#
• ETA to waypoint (ETA)
• Range to waypoint (RNG)
• Bering to waypoint (BRG)
• Route time-to-go (ROUTE TTG)
• Speed (SOG)
• Time-to-go to waypoint (TTG)
• Total route distance (ROUTE DIST)*
• Trip distance (TRIP)
• Trip elapsed time (TRIP TIME)
• Water temperature (WAT TEMP)#, and
• Velocity to destination (VTD)*
• ETA to route
*ALT: Displayed only in 3D position fixing.
*ROUTE DIST: Total distance from current
position to ultimate destination. Appears
when following a registered route or a
cursor-created route.
*VTD: When following a route, plus or minus
appears next to indication to denote which
direction the route is being traversed.
# Requires external sensor.
1) Press MENU ESC, 9 and 1 to display the
PLOTTER SETUP menu.
PLOTTER SETUP
Bearing REF
AUTO
(07 W)
MAN
(00 E)
ENT:Enter
MENU:Escape
Memory Apportion
MAG Variation
True
TRK = 1000 / 2000Pt
MAG
RL
GC
Calculation
User defined #1 SOG
User defined #2 COG
User defined #3 RNG
User defined #4 BRG
Figure 6-2 PLOTTER SETUP menu
2) Press
or to select one of four of
"User defined" (#1, #2, #3, #4).
3) Press
or to select data to display.
4) Press the NU/CU ENT key. To select the
data to display at other user defined
displays, repeat steps 2 and 3.
5) Press the MENU ESC key.
