FURUNO FAR-21x7(-BB)/28x7 SERIES
SP - 3 E3519S01L-P
5. POWER SUPPLY
1. Display unit 24 VDC or 100-230 VAC, 1ø, 50/60 Hz
FAR-21x7: 24 VDC, 2.3 A; 100-230 VAC, 0.7A (100 V)
FAR-28x7: 24 VDC, 3.2 A; 100-230 VAC, 0.9 A (100 V)
440 VAC, 1 ø, 50/60 Hz with optional transformer RU-1803
2. Processor unit FAR-2117/2817/2117-BB:
24VDC: 7.6A (8.5A), 100-115 VAC: 2.6A (3.0A),
220-230 VAC: 1.6A (1.7A)
FAR-2127/2827/2127-BB:
24 VDC: 8.8A (9.7A), 100-115 VAC: 3.0A (3.4A),
220-230 VAC: 1.8A (1.9A)
( ): Value for 42 rpm antenna unit
FAR-2827W:
100-115 VAC: 3.2A, 220-230 VAC: 1.6A
FAR- 2137S/2137S-BB/2837S/2837SW:
100-115 VAC: 3.0A, 220-230 VAC: 1.5A
3. Antenna unit S-band: 200/220/380/440 VAC
, 3ø, 50/60 Hz
Antenna voltage input (100 kt) Model
200 VAC,
ø3, 50 Hz,
220 VAC,
ø3, 60 Hz
380 VAC,
ø3, 50 Hz,
440 VAC,
ø3, 60 Hz
220 VAC,
ø3, 50 Hz
(HSC)
220 VAC,
ø3, 60 Hz
(HSC)
440 VAC,
ø3, 60 Hz
(HSC)
FAR-2137S(BB) 3.0 A 1.5 A 3.5 A 3.5 A 1.7 A
FAR-2837S 3.0 A 1.5 A 3.5 A 3.5 A 1.7 A
FAR-2837SW 3.0 A 1.5 A - - -
FAR-2137SW 3.0 A 1.5 A - - -
4. Console 115/230 VAC, 1ø, 50/60 Hz, 440 VAC, 1ø, 50/60 Hz (with optional
transformer RU-1803)
6. ENVIRONMENTAL CONDITIONS
1. Ambient temperature
Display unit/monitor/processor unit/control unit/power supply unit/transceiver unit
-15°C to +55°C
Antenna unit -25°C to +55°C (storage +70°C)
2. Relative humidity less than 95% at 40°C
3. Waterproofing
Display unit/processor unit/control unit/power supply unit:
Front panel: IP56, Rear panel: IP20
Antenna unit: IPX6
4. Vibration 2 Hz-5Hz to 13.2 Hz: Amplitude: ±1 mm ±10%
13.2 Hz to 100 Hz: Max. acceleration 7m/s
2
, fixed
7. COLOR
1. Display unit Chassis: 2.5GY5/1.5, Panel: N3.0 (fixed)
Monitor N2.5 (fixed)
2. Processor unit 2.5GY5/1.5
3. Control unit N3.0 (fixed)
4. Antenna unit N9.5 (fixed)
5. Power supply unit 2.5GY5/1.5
