Furuno FM-8900S User Manual

APPENDIX 7 THERMAL PRINTER UTP-58E
AP-25
How to set the DIP switch
The DIP switch functions to change printer specifications. Default specifications are shown as bold
and italic face in the table below.
*: Do not change the setting for pin no. 0 except to upgrade the software. If the printer is turned
on with pin no. 0 set for ON, the software will be overwritten.
Table 1: Communication system
Table 2: Command mode
Pin no. Function OFF ON
1 to 4 Communication system See table 1.
5 Bit length 8 bit 7 bit
6 Control system RTS/CTS Xon/Xoff
7 to 8 Command mode See table 2.
9 Upright/inverted printing Upright printing Inverted printing
0 Test pin* Normal mode (Setting disable)
Input method Baud rate Parity DP1 DP2 DP3 DP4
Serial
38400
None
OFF OFF OFF OFF
19200 ON OFF OFF OFF
9600 OFF ON OFF OFF
4800 ON ON OFF OFF
2400 OFF OFF ON OFF
38400
Odd
ON OFF ON OFF
19200 OFF ON ON OFF
9600 ON ON ON OFF
4800 OFF OFF OFF ON
2400 ON OFF OFF ON
38400
Even
OFF ON OFF ON
19200 ON ON OFF ON
9600 OFF OFF ON ON
4800 ON OFF ON ON
2400 OFF ON ON ON
Parallel - - ON ON ON ON
Command method DP7 DP8
Mode 1 (20 digits, compatible with μTP-5820) ON ON
Mode 2 (24 digits, compatible with μTP-5824) OFF ON
Mode 3 (32 digits, compliant with ESC/POS OFF OFF
HEX dump mode ON OFF
