SYSTEM CONFIGURATIONS
Basic configuration is shown with solid line.
Single configuration
Antenna Unit
GPA-021S*
Antenna Unit
GPA-020S**
Antenna Unit
GPA-017S**
Display Unit
12-24 VDC
MENU
ESC
NU/CU
ENT
LIST
DISPLAY
ROUTE
GO TO
MOB
MARK
12
3
4
EVENT
5
PLOT
ON/OFF
6
78
9
ZOOM
IN
CENTER
ZOOM
OUT
ACK
DELETE
CURSOR
ON/OFF
0
BRILL
110/220 VAC
USB Flash Memory
Switching Hub
HUB-100
Radar,
Echo Sounder,
Autopilot,
Printer (PP-505FP),
Beacon Receiver,
Interface Unit IF-2503
*: w/internal beacon receiver
**: w/o internal beacon receiver
Rectifier
PR-240
100 to 115/
200 to 230 VAC
Rectifier
PR-62
