Furuno GPS NAVIGATOR GP-150 User Manual

3. MARKS
3-3
3.4 Entering Event Marks
Event marks can denote any important
present position. Event marks can be saved
as ordinary marks and the unit automatically
numbers them from 01 to 99.
Note 1: When the mark memory becomes full
no event marks can be entered.
When this occurs, the buzzer sounds
and the message shown below
appears on the display for three
seconds to alert you. To enter an
event mark when the mark memory is
full, erase unnecessary event marks.
Can’t save event
Memory full
Figure 3-5
Entering event marks
1) Press the EVENT MOB key less than
three seconds. The position at the exact
moment the key is pressed is saved as an
event position.
Saved event position
34° 40.123’ N
135° 21.123’ E
Figure 3-6
To erase event marks, see "3.1
Entering/Erasing Marks".
3.5 Selecting Event Mark
Shape
Event marks are available in 10 shapes.
Select event mark shape as follows.
1) Press MENU ESC and 2 to display the
TRACK/MARK SETUP menu.
2) Press
or to select Event Mark.
3) Press
or to select event mark
shape desired.
4) Press the NU/CU ENT key.
5) Press the MENU ESC key.
The next event mark entered will be inscribed
in the shape selected here.

Furuno GPS NAVIGATOR GP-150 Specifications

General

Display Type	LCD
Display Size	4.5 inches
Resolution	320 x 240 pixels
Channels	12 channels
Interface	NMEA0183
Operating Temperature	-15°C to +55°C
Waterproof Standard	IPX6
GPS Accuracy	10 m (95%)
Update Rate	1 second
SBAS Accuracy	3 m (95% probability, HDOP ≤ 4)
