Furuno GPS NAVIGATOR GP-150 User Manual

A
P-1
MENU TREE
Main menu
ESC
MENU
1. DISPLAY SETUP
2. TRACK/MARK SETUP
3. ERASE TRACK/MARK
4. ALARM SETTINGS
5. MANUAL CALCULATION
6.
7. GPS MONITOR
Satellites Monitor
Beacon RCVR Monitor
Station Message
From
To
Trial Speed (AUTO, MAN)
(010.0 kn)
XTE (On, Off)
Arrival/Anchor (ARRV, ANCH., Off)
Ship Speed (In, Over, Off)
Trip (CLR:Reset) (On, Off)
Water TEMP (In, Over, Off)
Depth (In, Over, Off)
Alarm Range (0.250 NM)
Alarm Range (0.500 NM)
Speed Range (011.0 - 015.0 kn)
Trip Range (0100.00 NM)
TEMP Range (+11.0 - +15.0 ˚C)
Depth Range (0011.0 - 0015.0 ft)
WAAS/DGPS (On, Off)
Erase Track (No, Yes)
Erase Mark (No, Yes)
Grid (Dark, Light, Off)
Course Bar (Dark, Light, Off)
Time Mark (Dark, Light, Off)
Waypoint Size (Large, Small)
Track REC (Time, DIST)
Cursor Size (Large, Small)
Set/Drift AVR (Off, 10min, 20min, 30min,
1hr, 2hrs, 3hrs, 5hrs, 6 hrs)
,,,
Mark Shape (
Mark Line (
Event Mark (
8. SELF TESTS
1. Memory, I/O Port Test
2. Keyboard Test
3. Test Pattern
4. Automatic Testing
)
)
)
1

Furuno GPS NAVIGATOR GP-150 Specifications

General

Display Type	LCD
Display Size	4.5 inches
Resolution	320 x 240 pixels
Channels	12 channels
Interface	NMEA0183
Operating Temperature	-15°C to +55°C
Waterproof Standard	IPX6
GPS Accuracy	10 m (95%)
Update Rate	1 second
SBAS Accuracy	3 m (95% probability, HDOP ≤ 4)
