APPENDIX
AP-10
4. Parts List and Parts Location
This equipment contains complex modules in which fault diagnosis and repair down to
component level are not practical (IMO A.694(17)/8.3.1. Only some discrete components
are used. FURUNO Electric Co., Ltd. believes identifying these components is of no value
for shipboard maintenance; therefore, they are not listed in the manual. Major modules can
be located on the parts location photo on this and then next page.
F U R U N O Model SC-50
Unit SC-501
PROCESSOR UNIT
ELECTRICAL PARTS LIST Ref.Dwg. Page
Blk.No.
SYMBOL TYPE CODE No. REMARKS SHIPPABLE
ASSEMBL
Y
PRINTED CIRCUIT BOARD
20P8178, MAIN
20P8181, PWR
MAIN Board
(20P8178)
PWR Board
(20P8181)
Processor Unit, cover removed
