Garland Master Series Installation, Operating & Service Manual

Part # 4519069 (07/24/09) Page 9
TECHNICAL SPECIFICATIONS continued
Table F: Pressure Setting / Injector Size
MODEL/SECTION
2nd Family, Groups H, L & E 3rd Family, Group 3P
Setting Pressure
Injector Size
Setting Pressure Injector Size
G20 @ 20
mbar
G25 & 25
mbar
G31 @ 37/50
mbar
37 mbar 50 mbar
mbar “WC mbar “WC DMS mm mbar “WC DMS mm DMS mm
MST42(R,RC,S & T)(E) 20 8.0 25 10 – – 37/50 14.8/20 – – – –
MST43(R,RC,S & T)(E) 20 8.0 25 10 – – 37/50 14.8/20 – – – –
MST44(R,RC,S & T)(E) 20 8.0 25 10 – – 37/50 14.8/20 – – – –
MST45(R,RC,S & T)(E) 20 8.0 25 10 – – 37/50 14.8/20 – – – –
MST46(R,RC,S & T)(E) 20 8.0 25 10 – – 37/50 14.8/20 – – – –
MST47(R,RC,S & T)(E) 20 8.0 25 10 – – 37/50 14.8/20 – – – –
MST54(R,RC,S & T)(E) 20 8.0 25 10 – – 37/50 14.8/20 – – – –
MST4(S & T)(E) 20 8.0 25 10 – – 37/50 14.8/20 – – – –
MST6(S & T)(E) 20 8.0 25 10 – – 37/50 14.8/20 – – – –
MST7(S & T)(E) 20 8.0 25 10 – – 37/50 14.8/20 – – – –
MST40(E) Oven – – – – 31 2.65 – – 50 1.78 53 1.5
MST40RC(E) Oven – – – – 31 2.65 – – 50 1.6 53 1.5
MST42(E) Open Top – – – – – – – – – – – –
MST42(E)
Solid Top/Griddle
– – – – 45 2.08 – – 1.4 1.4 1.2 1.2
MST43(E) Open Top – – – – 1.9 1.9 – – 1.3 1.3 1.2 1.2
MST44(E) Open Top – – – – – – – – – – – –
MST45(E) Solid Top – – – – 1.4 1.4 – – 63 0.95 66 0.85
MST46(E) Solid Top – – – – 45 2.08 – – 1.4 1.4 1.25 1.2
MST47(E) Griddle – – – – 44 2.18 – – 53 1.51 1.35 1.3
MST54(E) Solid Top – – – – – – – – – – – –
MST54(E) Open Top – – – – – – – – – – – –
MST17B(E) Broiler 20 8.0 25 10 1.5 1.5 37/50 14.8/20 60 1.02 63 0.95
MST24B(E) Broiler 20 8.0 25 10 1.5 1.5 37/50 14.8/20 60 1.02 63 0.95
MST34B(E) Broiler 20 8.0 25 10 1.5 1.5 37/50 14.8/20 60 1.02 63 0.95
MST35F Fryer 10.5 4.2 N/A N/A 1.7 1.7 22.4 9.0 1.0 1.0 1.0 1.0
MST70F Fryer 10.5 4.2 N/A N/A 1.2 1.2 22.4 9.0 0.82 0.82 0.82 0.82
