37
Appendix C
The eMap uses “pop-up” messages to alert you to unit operating characteristics.
Press the ENTER key to acknowledge and return to the page you were viewing.
Approaching Turn - You are less than one minute away from a turn in your
route.
Arriving at Destination - You have reached your destination.
Base Map Failed - The unit’s base map has failed. Return your unit to GARMIN
for service.
Batteries Low - The batteries in your unit are low and no longer capable of
supporting unit operation. Install new batteries.
Database Error - There was an error in the unit’s database.
GPS Turned Off (for use indoors) - The eMap’s GPS receiver has been turned
off to conserve battery power and speed Map Page display drawing.
Lost Satellite Reception - The unit has lost satellite signals. Try moving to
another location with a clearer view of the sky.
Memory Full - The unit’s memory is full. To reduce the amount of memory
used, delete unused routes, waypoints or tracks.
No Differential GPS Position - The beacon receiver is not communicating
with the unit. Refer to the ‘Interface’ setup page of the unit to view the ‘Status’ field.
None Found - There is no such address, intersection, point of interest, or city
in the map information database. Check spelling or number entry and try again.
RAM Failed - The eMap has detected a failure in its internal memory. If the
message persists, service is required.
ROM Failed - The permanent memory has failed and the unit is not operable.
Service is required.
Route Already Exists - The name you selected has already been assigned.
Choose another name.
Route Memory Full - No additional route waypoints can be added.
Route Truncated - A complete uploaded route will not fit into memory. Modify
the route to reduce size.
Route Waypoint Memory Full - There is no more space for map-based
waypoints.
Track Already Exists - The name selected has been assigned.
Track Memory Full - All of the saved track locations are used.
Track Truncated - A complete uploaded track will not fit into memory. Clear
existing track memory or reduce the amount of new track data.
Transfer Complete - The eMap has finished uploading or downloading
information to the connected device.
Waypoint Already Exists - The name you selected has already been assigned.
Choose another name.
Waypoint Memory Full - All of the waypoints have been assigned.
Messages
