Unit Operation
Setup Menu/Units
Units
The ‘Units’ tab contains settings for ‘Depth’, ‘Temperature’ and ‘Speed’.
To access the ‘Units’ tab, use the arrow keys to highlight it.
Depth
The ‘Depth’ field can be configured to display in Feet (ft), Meters (mt)
or Fathoms (fa).
To Select a Depth Unit:
1. Highlight the ‘Units’ tab on the Setup Menu.
2. Highlight the ‘Depth’ field and press ENTER.
3. Select ‘Feet’, ‘Meters’, or ‘Fathoms’, press ENTER to accept the new setting.
Temperature
If equipped with a temperature capable transducer, the unit can display
water temperature in Fahrenheit (°F) or Celsius (°C).
To Select a Temperature Unit,
1. Highlight the ‘Units’ tab on the Setup Menu.
2. Highlight the ‘Temperature’ field and press ENTER.
3. Select ‘Fahrenheit’ or ‘Celsius’ press ENTER to accept the new setting.
Speed
If equipped with a speed capable transducer, the unit can display the
boat’s ‘Speed’ Over Water. The unit can be configured to display in ‘Nautical
Miles-Per-Hour’ (kt), ‘Kilometers-Per-Hour’ (kh), or ‘Miles-Per-Hour’ (mh).
To Select a Speed Unit:
1. Highlight the ‘Units’ tab on the Setup Menu.
2. Highlight the ‘Speed’ field and press ENTER.
3. Select ‘Miles’, ‘Kilometers’, or ‘Knots’, press ENTER to accept the
selection.
Depth Selections
Speed Selections
Temperature Selections
