Fishfinder 160C Owner’s Manual 11
INSTALLING THE FISHFINDER 160C > WIRING HARNESS INSTALLATION
Wiring Diagram
2A
-
+
Red +
Wiring to a Fuse Block
Black -
(red) + 10-18 VDC
(black) - Ground (Power/Data)
(blue) Port 1 Data OUT
(yellow) Alarm Low
GPS/NMEA
Device
10-18 volts
DC
Power
RXD +
TXD +
Alarm Relay
100ma max
coil current
To Transducer
To Unit

Garmin Fishfinder 160C Specifications

General

Display resolution	128 x 128 pixels
Audible alarm(s)	Yes

Weight and Dimensions

Weight	499 g
Dimensions (WxDxH)	155 x 74 x 124 mm
