Fishfinder 160C Owner’s Manual 17
OPERATING INSTRUCTIONS > THE SETUP MENU
Beam
The Beam setting allows the selection of a Narrow Beam or Wide
Beam for the transducer. A narrow beam provides higher detail
structure returns of a smaller bottom area. The wide beam shows a
larger fish return area with poorer detail of non-bottom structure.
Whiteline
The Whiteline setting controls how the unit displays information
about the bottom type (hard or soft). With Whiteline off, the bottom
return displays as a solid color. With Whiteline
on, the strongest
area of bottom return becomes white and can be used to determine
bottom hardness. A hard bottom returns a stronger signal and
displays a thicker bottom layer. A soft bottom returns a weaker
signal and displays a thinner bottom layer.
Whiteline Off
Whiteline On
Hard Bottom Soft Bottom
Auto Gain
The Auto Gain setting controls the sensitivity of the receiver when in
the gain option is set to Auto. Auto Gain has three
settings; High, Medium, and Low. Increasing the
Auto Gain setting makes the Fishfinder 160C more
aggressive when adjusting gain automatically.
High auto gain may lead to excessive clutter on the
screen.
