18 Fishfinder 160C Owner’s Manual
OPERATING INSTRUCTIONS > THE SETUP MENU
Background
Use this setting to change the Background
color. The available settings are: Black,
Blue, and White.
Numbers
Keel Offset
Use the Keel Offset setting to offset the surface
reading for the depth of a keel. This makes it
possible to measure depth from the bottom of your
keel instead of from the transducer’s location.
Enter a positive number to offset for a keel. You
can enter a negative number to compensate for a
large vessel that may draw several feet of water.
Size
Determines the size of the depth, battery,
temperature, speed, and distance numbers shown
on the screen, either Small or Large (default).
Battery
Choose to either Hide (default) or Show the
current battery voltage.
Water Temp
Water Temperature automatically
appears when set to Auto (default),
or you can choose to Hide the Water
Temperature.
Speed
Speed automatically appears when set to Auto
(default), or you can choose to Hide the Speed.
Distance
Distance automatically appears when set to
Auto, or you can choose to Hide (default)
the Distance.
Transducer at Surface
Enter (+) positive
number to show depth
from the bottom of keel.
Transducer at Bottom
of Keel
Enter (-) negative number to
show depth from the surface.

Garmin Fishfinder 160C Specifications

General

Display resolution	128 x 128 pixels
Audible alarm(s)	Yes

Weight and Dimensions

Weight	499 g
Dimensions (WxDxH)	155 x 74 x 124 mm
