190-00303-05 GIA 63 Installation Manual
Rev. Y Page 1-3
1.4 Technical Specifications
1.4.1 Environmental Qualification Form
It is the responsibility of the installing agency to obtain the latest revision of the GIA 63(X) Environmental
Qualification Form. This form is available directly from Garmin under the following part number:
GIA 63 Environmental Qualification Form, Garmin part number 005-00148-02
GIA 63W Environmental Qualification Form, Garmin part number 005-00235-00
The GIA 63H and the GIA 63W are included in the 005-00235-00. To obtain a copy of this form, see the
dealer/OEM portion of the Garmin web site (www.garmin.com).
1.4.2 Physical Characteristics
Table 1-1. GIA 63(X) Physical Characteristics
Characteristic Specification
Modular Rack Width 3.83 inches (97.3 mm)
Modular Rack Height 7.26 inches (184.4 mm)
Standalone Rack Width 3.88 inches (98.5 mm)
Standalone Rack Height 6.91 inches (175.5 mm)
Depth w/connectors (Modular and Standalone) 10.20 inches (259.1 mm)
Unit Weight
011-00781-0X: 5.3 lbs. (2.40 kg)
011-01105-0X/-1X/-2X: 5.3 lbs. (2.40 kg)
011-01105-4X: 5.5 lbs. (2.49 kg)
Modular Rack Weight w/Back Plate 1.0 lbs. (0.45 kg)
Standalone Rack Weight w/Back Plate 1.3 lbs. (0.59 kg)
Helicopter Rack Width 3.76 inches (95.4 mm)
Helicopter Rack Height 7.00 inches (177.8 mm)
Depth w/connectors (Helicopter) 10.18 inches (258.6 mm)
Unit Weight (Helicopter) 011-01105-3X: 5.4 lbs (2.45 kg)
Helicopter Rack Weight w/Back Plate 1.6 lbs (0.74 kg)
Connector Kit Weight*
011-01000-00: 1.3 lbs (0.59 kg)
011-01000-01: 1.1 lbs (0.50 kg)
011-01000-03: 1.1 lbs (0.50 kg)
* Only the GIA 63H unit (011-01105-3X) together with the Helicopter Rack (011-02425-00), Back Plate (011-00963-01), and Connector Kit
(011-01000-01) is approved for DO-160F, Category U, Curve G vibration levels.
