190-00303-05 GIA 63 Installation Manual
Rev. Y Page 2-1
2 INSTALLATION OVERVIEW
2.1 Introduction
This section provides hardware equipment information for installing the GIA 63(X), related hardware, and
antennas. Installation of the GIA 63(X) should follow the aircraft TC or STC requirements. Cabling is
fabricated by the installing agency to fit each particular aircraft. The guidance of FAA advisory circulars
AC 43.13-1B and AC 43.13-2B, where applicable, may be found useful for making retro-fit installations
that comply with FAA regulations. Refer to the G1000 System Installation Manual, Garmin part number
190-00303-00 for further details on the mechanical aspects. For installation in an aircraft using the remote
mounted standalone rack, refer to Appendix B for rack drawings and dimensions.
2.1.1 Unit Configurations
The GIA 63(X) is only available as a single unit under the following part numbers.
Table 2-1. GIA 63(X) Part Numbers
Item Garmin P/N
GIA 63 Unit Only, (011-00781-00) 010-00335-00
GIA 63 ETSO Unit Only, (011-00781-01) 010-00335-10
GIA 63W Unit Only, (011-01105-00) 010-00386-00
GIA 63W A2/B2 Audio Lightning Unit Only (011-01105-01) 010-00386-10
GIA 63W Updated NAV/COM (011-01105-20) 010-00386-20
GIA 63H (011-01105-30)* 010-00386-30
GIA 63W with Enhanced COM (011-01105-40) 010-00386-40
*Only the 010-00386-30 GIA 63H unit together with the 011-02425-00 Rack & 011-00963-01 Back Plate is approved for DO-160F,
Category U, Curve G vibration levels.
