GMA 1347D Installation Manual Page 1-3
190-00303-21 Revision C
1.3 Technical Specifications
It is the responsibility of the installing agency to obtain the latest revision of the GMA 1347D
Environmental Qualification Form. This form is available directly from Garmin under the following part
number:
GMA 1347D Environmental Qualification Form, Garmin part number 005-00314-79
To obtain a copy of this form, see the dealer/OEM portion of the Garmin web site (www.garmin.com)
.
1.3.1 Physical Characteristics
Characteristic Specification
Bezel Height 7.70 inches (196 mm)
Bezel Width 1.30 inches (33 mm)
Rack Height 6.30 inches (160 mm)
Rack Width 1.325 inches (34 mm)
Depth Behind Panel with
Connectors (measured from face
of aircraft panel to rear of
connector backshells)
7.79 inches (198 mm)
GMA 1347D Unit Weight 1.7 lbs. (0.8 kg)
GMA 1347D Rack Weight
(Installed with rack and
connectors)
2.4 lbs. (1.1 kg)
