GMA 1347D Installation Manual Page 4-7
190-00303-21 Revision C
4.3.3 RS-232 Serial Input/Output
Table 4-5. RS-232 Pin Assignments, J3472
Pin Pin Name Description I/O
6 RS-232 OUT 1 Output level greater than ±5 Volts Out
7 RS-232 IN 1 Input level up to ±25 volts In
38 RS-232 OUT 2 Output level greater than ±5 Volts Out
39 RS-232 IN 2 Input with level up to ±25 volts In
The RS-232 outputs conform to EIA/TIA-232C with an output voltage swing of at least ±5 V when
driving a standard RS-232 load. Refer to Figure B-5 for the RS-232 serial data interconnections.
4.3.4 Marker Beacon Functions
Marker Beacon connections are listed in the following table. The antenna input is connected to pins 78
(HI or Center Conductor) and 59 (LO or Shield).
Table 4-6. Marker Beacon Pin Assignments, J3472
Pin Pin Name Description I/O
34 MIDDLE MARKER SENSE
2.5-8 Vdc into 4.7 k
Out
74
AIRWAY/INNER MARKER EXT
LAMP OUT (-00)
MKR I-HI white 2.5-8 Vdc into 56
Out
75 MIDDLE MARKER EXT LAMP OUT
MKR M-HI amber. 2.5-8 Vdc into
56
Out
76 OUTER MARKER EXT LAMP OUT
MKR O-HI blue. 2.5-8 Vdc into 56
Out
78 MARKER ANTENNA HI
Marker antenna input, 50
In
59 MARKER ANTENNA LO Ground reference for pin 78 --
4.3.5 Reversionary Mode
The reversionary mode pins are used in installations having more than one GDU that have a
GMA 1347D. The GMA 1347D contains a display backup button. This button is used to switch the PFD
and MFD display data.
Table 4-7. Reversionary Mode Pin Assignments, J3472
Pin Pin Name Description I/O
36 REVERSIONARY MODE 1 PFD connect Out
37
REVERSIONARY MODE
COMMON 1
Ground reference for mode 1 --
56 REVERSIONARY MODE 2 MFD connect Out
57
REVERSIONARY MODE
COMMON 2
Ground reference for mode 2 --
