Garmin GTR 225 User Manual

190-01182-02 GTR 225/GNC 255 TSO Installation Manual
Rev. F Page D-14
NOTES
Figure D-7 GNC - VOR/ILS Interconnect
Sheet 2 of 2
ALL WIRES 24 AWG OR LARGER UNLESS OTHERWISE SPECIFIED.
GROUND DESIGNATIONS: SHIELD BLOCK GROUND AIRFRAME GROUND
AT THE GNC, CONNECT SHIELD GROUNDS TO THE CONNECTOR BACKSHELL - THE SHIELD TERMINATION
LEADS SHOULD BE LESS THAN 3.0". CONNECT OTHER END OF THE SHIELD PER THE REMOTE EQUIPMENT
INSTALLATION REQUIREMENTS.
REFER TO MANUFACTURER’S DOCUMENTATION FOR COMPLETE PINOUT AND INTERCONNECT
INFORMATION. PINOUTS OF OTHER UNITS SHOWN FOR REFERENCE ONLY.
1
2
S
3
4

Garmin GTR 225 Specifications

General

Input Voltage	11-33 VDC
Operating Voltage	11-33 VDC
Operating Temperature	-20°C to +55°C
Frequency Range	118.000 MHz to 136.975 MHz
Channel Spacing	25 kHz
Transmit Power	10 W
Current Consumption	1.5 A (max transmit)
