190-01182-02 GTR 225/GNC 255 TSO Installation Manual
Rev. F Page 4-3
4.5 Special Tools Required
Some of the connectors use crimp contacts. The table below identifies crimp tools required to ensure
consistent, reliable crimp contact connections for the rear D-sub connectors.
Table 4-5 Recommended Crimp Tools (or Equivalent)
NOTE
Insertion/extraction tools from ITT Cannon are all plastic; others are plastic with metal
tip.
Table 4-6 Socket Contact P/Ns
[1] Non-Garmin part numbers shown are not maintained by Garmin and are subject to change
without notice.
Manufacturer
Hand Crimping
Tool
22 – 28 AWG (P2001 – P2002)
Positioner
Insertion/
Extraction Tool
Military P/N M22520/2-01 M22520/2-09
M81969/14-01
M81969/1-04
Positronic 9507-0-0-0 9502-4-0-0 M81969/1-04
ITT Cannon 995-0001-584 995-0001-739
000849490
274-7048-000MIL
AMP 601966-1 601966-6
91067-1
2031838-1
Daniels AFM8 K42
M81969/14-01
M81969/1-04
Astro 615717 615725
M81969/14-01
M81969/1-04
Wire Gauge
P2001-P2002
22-28 AWG
Garmin P/N 336-00021-00
Military P/N M39029/58-360 [1]

Garmin GTR 225 Specifications

General

Input Voltage	11-33 VDC
Operating Voltage	11-33 VDC
Operating Temperature	-20°C to +55°C
Frequency Range	118.000 MHz to 136.975 MHz
Channel Spacing	25 kHz
Transmit Power	10 W
Current Consumption	1.5 A (max transmit)
