GE Multilin C30 Controller System 6-9
6 ACTUAL VALUES 6.2 STATUS
6
6.2.16 IEC 61850 GOOSE INTEGERS
PATH: ACTUAL VALUES  STATUS  IEC 61850 GOOSE UINTEGERS
The C30 Controller System is provided with optional IEC 61850 communications capability. This feature is
specified as a software option at the time of ordering. Refer to the Ordering section of chapter 2 for addi-
tional details.
The IEC 61850 GGIO5 integer input data points are displayed in this menu. The GGIO5 integer data values are received
via IEC 61850 GOOSE messages sent from other devices.
6.2.17 EGD PROTOCOL STATUS
a) FAST EXCHANGE
PATH: ACTUAL VALUES  STATUS  EGD PROTOCOL STATUS  PRODUCER STATUS  FAST EXCHANGE 1
These values provide information that may be useful for debugging an EGD network. The EGD signature and packet size
for the fast EGD exchange is displayed.
b) SLOW EXCHANGE
PATH: ACTUAL VALUES  STATUS  EGD PROTOCOL STATUS  PRODUCER STATUS  SLOW EXCHANGE 1(2)
These values provide information that may be useful for debugging an EGD network. The EGD signature and packet size
for the slow EGD exchanges are displayed.
 IEC 61850
 GOOSE UINTEGERS
UINT INPUT 1
0
MESSAGE
UINT INPUT 2
0
↓
MESSAGE
UINT INPUT 16
0
 FAST EXCHANGE 1

FAST EXCHANGE 1
SIGNATURE: 0
MESSAGE
FAST EXCHANGE 1
DATA LENGTH: 0
 SLOW EXCHANGE 1

SLOW EXCHANGE 1
SIGNATURE: 0
MESSAGE
SLOW EXCHANGE 1
DATA LENGTH: 0
