– 52 –
Cabinet/Apron Assembly
The cabinet/apron assembly consists of the cabinet,
top corner brackets, and bottom corner brackets.
The leveling legs can be ordered separately if
needed. If the legs are replaced, ensure that
the washer has been leveled according to the
Installation Instructions.
Cabinet/Apron Removal
To remove the cabinet/apron assembly, two
technicians will be needed because of the bulkiness
of the cabinet/apron assembly. The weight of
the cabinet/apron assembly is approximately
30 pounds. A height of at least 70 in. will also be
needed to lift the cabinet/apron assembly up and
over the top of the tub assembly.
1. Remove the backsplash and top cover assembly.
2. Disengage the rod and spring assembly from
the tub. One technician will lift up on the
tub assembly while the second technician
disengages the rod and spring assembly.
7KHWXEDVVHPEO\ZLOOVLWRQWKHÀRRURQWKHEHOW
protector.
3. Lift the cabinet/apron assembly up and over the
tub assembly and set it aside.
Leveling Legs
Keeping the washer level is critical because the
clearance of the tub to the cabinet/apron assembly
is minimal. It also assists with preventing the washer
from rocking and moving out of position.
Leg Adjustment
0RYHWKHZDVKHULQWRLWV¿QDOSRVLWLRQ3ODFHDOHYHO
RQDÀDWWRSVLGHHGJHRIWKHZDVKHU$GMXVWDOOIRXU
leveling legs by screwing them into or out of the four
brackets until the washer is level, right to left and
back to front.
Replace any of the leveling legs if they show signs of
damage.
