Kilsen KFP-CF Series Operation Manual 7
Item Control/LED LED colour Description
21 Fire Routing
Fault/Disable/Test
button and LED
Yellow Indicates that fire routing is in a fault condition, is
disabled, or is being tested.
A flashing LED indicates a fault. A steady LED
indicates that the function is disabled or is being
tested.
Acoustic indicators
The control panel uses the following acoustic indicators to highlight system events.
Indication Description
The internal buzzer sounds
constantly
Indicates a fire alarm or a system
fault
The internal buzzer sounds
intermittently
Indicates all other faults
Summary of status indications
This section includes a summary of the control panel status indications.
Standby (normal status)
Standby, or normal status, is indicated as follows:
• The Supply LED is steady.
• If a sounder delay was enabled, the Sounder Delay LED is steady.
• If a fire routing delay was enabled, the Fire Routing Delay LED is steady.
• There are no acoustic indications.
Fire alarm
Fire alarm status is indicated as follows:
• The general Fire Alarm LEDs are flashing if the alarm was activated by a detector
or steady if the alarm was activated by a manual call point.
• The corresponding zone alarm LEDs are flashing if the alarm was activated by a
detector or steady if the alarm was activated by a manual call point.
• If a sounder delay was enabled, the Sounder Delay LED is steady. The Sounder
Start/Stop LED flashes while the delay is active. When the sounders are active
(sounding), the LED is steady.
• If a fire routing delay was enabled, the Fire Routing Delay LED is steady. The Fire
Routing Start LED flashes while the delay is active. When fire routing is active, the
LED is steady.
• The internal buzzer sounds constantly.
Alarms activated by a manual call point always take priority over alarms activated by
a detector. If an alarm is activated by both devices, the Fire Alarm LEDs and zone
alarm LEDs are steady.
