Menu Structure
There are four levels within the M-PRO menu structure, the main three are described below. Only those menus specified at the time of
ordering will be factory set into M-PRO hence not all of the following menus will be available.
Level 1 Menu Level 2 Menu Level 3 Menu Level 4 Menu
I set e.g: 40% In
Curve Type e.g: Standard Inverse
Curve Speed e.g: Curve 6
Cooling Time e.g: Instantaneous
Inverse Short Circuit
Current
e.g: 4 x Iset
Fixed Short Circuit Current e.g: 6 x Iset
Fixed Short Delay e.g: 300ms
Neutral Rating e.g: Fully Rated
Curve Settings
Phase Rotation e.g: RYB Clockwise
REF Current e.g: 10% In
REF Alarm e.g: ON
UEF Current e.g: 30% In
UEF Trip Time e.g: 400ms
UEF Cropping e.g: 2.5
SEF Current e.g: 50% In
SEF Trip Time e.g: 500ms
SEF Cropping e.g: 4
Earth Protection
1,2
SEF Intertrip e.g: ON
Load Monitoring e.g: Load
shedding/pretrip alarm
Start Shedding e.g: 95% x Iset
Protection
Load Monitoring
1,2
Stop Shedding e.g: 80% x Iset
Red Ylw Blue (A)
Red Ylw Blue (% I
set)
Neutral (% I set)
Highest Phase (A)
Peak RMS Phase
(A)
SEF Current (A)
REF Current (A)
UEF Current (A)
Ammeters
Thermal Register
(%)
Input 1 e.g: warn
Input 2 e.g: warn
Input 3 e.g: warn
Input Settings
1,2
Input 4 e.g: warn
Existing Faults e.g: No FaultsFaults
History of Trips e.g: Overload Trip on Red
Breaker position e.g: Closed
Contact Life e.g: 10%
Total Life e.g: 70%
Breaker Status
No. of Operations e.g: 3020
M-PRO Status Powered Up Time e.g: 500 minutes
Software Issue e.g: 5201D06, 6A4AHSoftware Status
EPROM Name e.g: M-PRO 5201 D6
System Status
PAMM Status PAMM Identity e.g: 40/F/A9A4701H
Baud Rate e.g: 9600
Link Scan Range e.g: 0.01 to 0.03
Link Scan Time e.g: 44 seconds
Link Timeouts e.g: 2
Link Status
CRC Errors e.g: 0
Link Address e.g: 3
Baud Rate Setup e.g: automatic
Communications
2
Link Setup
Link Fail Action e.g: warn
Fault Crnt Type e.g: Over Current
Over Crnt Level e.g: 2 x Iset
Earth Crnt Level e.g: 20%
Test Mode (available
when test box is
inserted and switched
on)
Activate Test e.g: Start Test
1
Options for M-PRO 30
2
Options for M-PRO 40
