Inspection and Maintenance — GEK 107048Combustion Inspection — Inspection Procedures
CI-I-24
Table CI-5
Inspection Limits, for Flow Sleeves
See Figure CI-I.12
CAUTION
The inspection criteria in this Table CI-5 applies to
General Electric Company supplied transition pieces only.
Inspect
Maximum Acceptable
Limits
Disposition (For Parts
Beyond Max. Limits)
Sleeve
1. Cracks None *Replace
2. Distortion 0.125 inch out of round Reform
3. Wear (Pilot Diameter) 0.010 inch per side *Replace
Flange
1. Distortion 0.010 inch out of round *Replace
2. Drain hole blockage None Clean
*“Replace” does not mean liner must be scrapped; part can be repaired by qualified General Electric
Company personnel.
2. Use Figures CI-I.12 and CI-I.13 for identification of parts and Table CI-6 for Inspection Limits.
Record findings on Inspection Form PGS/GT–FF–6410.
3. Reconnect the spark plug load, with the spark plug removed from the turbine. Rest the body of
the spark plug against the turbine shell (or other grounded metal). Make sure the electrode end of
the spark plug is not grounded.
**WARNING**
Do not test ignitors in or near an area with an explosive
atmosphere.
Be careful of high voltage.
4. Energize the ignition circuit and check the spark of the spark plug for approximately two minutes.
If heating occurs along the length of the plug or the spark is weak or erratic, loosen the swagelock
fitting and slide out the spark plug and replace it. Do not compress the swagelock fitting at this
time.
