Standard PracticesInspection and Maintenance — GEK 107048
SP-15
Special Tools — Typical for MS-6001B Gas Turbine with DLN-1
Note: Refer to the Tool Lists, line items A033 and 0104, in the Parts Volume
Service Manual for list of tools furnished for your unit(s).
Tool Name Application Quantity Figure
Guide Pin For Disassembly and Reassembly of Inlet
Casing
4 2-2
Guide Pin For Disassembly and Reassembly of
Compressor Casing
4 2-3
Guide Pin For Disassembly and Reassembly of Number
One Bearing
4 2-4
Guide Pin For Disassembly and Reassembly of Number
Two Bearing
4 2-4
Guide Pin For Disassembly and Reassembly of Exhaust
Frame
4 2-4
Guide Pin For Disassembly and Reassembly of
Compressor Discharge Casing
4 2-5
Guide Pin For Disassembly and Reassembly of Turbine
Casing
4 2-5
Jacking Bolt For Jacking Number One Bearing, Forward
and Aft Compressor Casing (0.750-10 x
4.00)
4 2-6
Jacking Bolt For Jacking Compressor Discharge Casing
(1.50-8 x 5.00)
6 2-6
Jacking Bolt For Jacking Compressor Discharge Casing
(1.50-8 x 3.25)
6 2-6
Jacking Bolt For Jacking Turbine Casing (1.750-8 x 6.00) 4 2-6
Jacking Bolt For Jacking Turbine Casing (1.750-8 x 4.50) 4 2-6
Jacking Bolt For Jacking Turbine Exhaust Frame (1.00-8 x
2.50)
4 2-6
Jacking Rod Bearing For Number Two
Bearing Disassembly
4 2-7
Fixture Arrangement
Disassembly and
Reassembly
For Disassembly and Reassembly of Number
Two Bearing and Load Coupling
1 2-8
Wrench, Fuel Nozzle For Disassembly and Reassembly of Fuel
Nozzles
2 2-9
Tool, Alignment Pin For Aligning Outer Combustion Casing
During Assembly
1 2-10
Tool, Transition Piece
Go/No Gauge
Measure End Clearances Between Adjacent
Transition Pieces
1 2-11
