– 20 –
Control Board
Inverter Board
Circuit Board Connections
J3
Input from
Power Board
DC Input Voltage
from Control Board
120 VAC Input From Control Board
Output To Motor
CN3
Output to Control Board
(Continued Next Page)
VFD (Vacuum Fluorescent Display)
