Door Lock
The door lock contains a door switch and solenoid operated locking and unlocking
mechanism.
The door locks when a cycle is entered (wake-up routine) and during every cycle. The
door unlocks at the completion of a cycle. The door will not open when:
The foam switch is open
Water temperature is above 130°F (54°C)
Wash basket is rotating
Specific failures associated with the door lock can initiate error codes E11 thru E13, and
E28. (See Service Test Mode.)
The door lock is held to the front panel with 3 Phillips-head screws. The door lock is
accessed from the front of the washer when the right side of the gasket is partially pulled
back.
CONFIDENTIAL AND PROPRIETARY INFORMATION-NOT FOR PUBLIC DISCLOSURE. September 2008
