26
Dispenser Motor
The dispenser is operated by a 120-VAC, 60-Hz motor. The dispenser motor receives
commands from the control board and controls dispenser operation.
Operation of the dispenser motor can be checked by using the Service Test Mode t12.
(See Service Test Mode.)
Specific failures associated with the dispenser motor can initiate error codes E38, E39,
and E62. (See Service Test Mode.)
To remove the dispenser motor:
Access the dispenser assembly. (See Dispenser Assembly.)
Caution: Lock tabs on the dispenser motor wiring harnesses are fragile. Tab breakage
can occur if excessive release pressure is applied.
Note: In the following step, it can be helpful to insert a small flat blade screwdriver (as
shown) to remove the wire harnesses.
CONFIDENTIAL AND PROPRIETARY INFORMATION-NOT FOR PUBLIC DISCLOSURE. September 2008
