80018C_MSW_2400-2500-Profibus_1209_ENG
Page 5
3.3 EXAMPLE OF PROFIBUS NETWORK WITH HARDWARE NODE ADDRESS SELECTION
HMI
Profibus Slave
node 1
PLC
Profibus Master
Class 1 node 2
DRIVE
Profibus Slave
node 3
2500
Profibus Slave
node 4
2500
Profibus Slave
node 5
2500
Profibus Slave
node 99
2500
Modbus
Node 1
2500
Modbus
Node 1
2500
Modbus
Node 1
2500
Profibus Slave
node 6
2500
Modbus
Node 1
