gefran 600 User Manual

(tr
hd.1
• Hrd
Hrd
Hardware configuration
Enable multiset
instrument control
by serial
Val Multiset Reversed Instrument
(2 SP) LED control by
state serial
0
1 x
2 x
3 x x
4 x
5 x x
6 x x
7 x x x
Control type
Val Control type
0 P heat
1 P cool
2 P heat / cool
3 PI heat
4 PI cool
5 PI heat / cool
6 PID heat
7 PID cool
8 PID heat / cool
9 ON-OFF heat
10 ON-OFF cool
11 ON-OFF heat / cool
12 PID heat + ON-OFF cool
13 ON-OFF heat + PID cool
14 PID heat + cool with relative gain
(see C.MEd parameter)
Selection of derivative action sampling time:
+ 0 sample 1 sec.
+ 16 sample 4 sec.
+ 32 sample 8 sec.
+ 64 sample 240 msec.
Note: LbA alarm is not enabled with ON/
OFF type control
• Prot
Pro
Protection code
Prot Display Modification
0 SP, In2, alarms, OuP, INF SP, alarms
1 SP, In2, alarms, OuP, INF SP
2 SP, In2, OuP, INF
+ 4 to disable InP, Out
+ 8 to disable CFG, Ser,
+ 16 to disable SW “power-up - power down”
+ 32 disable manual power latching
+ 64 to disable manual power modification
+128 enables full configuration
980336L_MHW_600_07-2011_ENG
9 / 31
