geminox FCX 22 C User Manual

- 27 -
INSTALLATION
Example:
- Installation: 100 litres
- Domestic hot water tank: 5 litres
- Boiler: 16 litres
- Total water capacity: 121 litres
Conditions: Using a vessel pre-loaded to 1 bar
(under floor boiler = ground floor hea
-
ting + 1 floor), heating safety valve
calibrated at 3 bars, installation filled
cold at 1 bar.
- Vessel efficiency calculation (R):
+ 1) = the transformation of relative pressures into abolute
pressures
- Calculation of the useful capacity of the vessel
(Cu):
- Calculation of the real capacity of the vessel (Cr):
R
Safety Pressure - Filling pressure()
Safety Pressure
------------------------------------------------------------------------------------=
R
31+()11+()–
31+()
----------------------------------------05,==
Cu total volume expansion×=
Cu 121 0 06,× 726dm
3
,==
Cr
Cu
R
-------=
Cr
726,
05,
------------ 14 5litres,==
7.3 - Hydraulic connection for models FCX to a single heating circuit
3
3
2
2
7
7
9
8
14
10
6
5
11
FCX-33-3
4
1
12
13
Fig. 44
1) Boiler
2) 1
st
heating circuit flow
3) 1
st
heating circuit return
4) Cold water inlet
5) Filling system**
6) Filling valves **
7) Heating flow/return isolating valves **
8) Boiler drain
9) Condensate drain
10)Filling system outlet
11)Sewer drain
12)2
nd
heating circuit outlet/ Primary flow - (outlet
from the boiler to the domestic hot water produc-
tion system) - (option)
13)2
nd
heating circuit return/ Primary return - (return
from the domestic hot water production system
to the boiler) - (option)
14)Isolating valve **
** accessories not supplied
