Gigabyte GA-X99-UD7 WIFI User Manual

- 21 -
Hardware Installation
1-7 Back Panel Connectors
Activity LED
Connection/
Speed LED
LAN Port
USB 2.0/1.1 Port
TheUSBport supports the USB2.0/1.1specication. Use this portforUSB devices such asaUSB
keyboard/mouse,USBprinter,USBashdriveandetc.
PS/2 Keyboard/Mouse Port
Use this port to connect a PS/2 mouse or keyboard.
CPUOverclockingButton
Press this button to overclock your CPU. To return to the defaults, press this button again.
Fast Boot Button
PressthisbuttondowntoenablethefastbootfunctiontoshortenOSboottime.(Makesuretosetthis
buttonbeforesystempower-on;otherwise,itwilltakeeffectatnextboot.)
Clear CMOS Button
UsethisbuttontocleartheCMOSvalues(e.g.BIOSconguration)andresettheCMOSvaluestofactory
defaults when needed.
USB 3.0/2.0 Port
TheUSB3.0portsupportstheUSB3.0specicationandiscompatibletotheUSB2.0/1.1specication.
UsethisportforUSBdevicessuchasaUSBkeyboard/mouse,USBprinter,USBashdriveandetc.
USB 3.0/2.0 Port (White)
TheUSB3.0portsupportstheUSB3.0specicationandiscompatibletotheUSB2.0/1.1specication.
UsethisportforUSBdevicessuchasaUSBkeyboard/mouse,USBprinter,USBashdriveandetc.
BeforeusingQ-FlashPlus,makesuretoinserttheUSBashdriveintothisportrst.
RJ-45 LAN Port (LAN1/2)
The Gigabit Ethernet LAN port provides Internet connection at up to 1 Gbps data rate. The following
describes the states of the LAN port LEDs.
Center/Subwoofer Speaker Out Jack (Orange)
Usethisaudiojacktoconnectcenter/subwooferspeakersina5.1/7.1-channelaudioconguration.
Rear Speaker Out Jack (Black)
Thisjackcanbeusedtoconnectfrontspeakersina4/5.1/7.1-channelaudioconguration.
• Whenremovingthecableconnectedtoabackpanelconnector,rstremovethecablefromyour
device and then remove it from the motherboard.
• When removing the cable, pull it straight out from the connector. Do not rock it side to side to prevent
an electrical short inside the cable connector.
Connection/Speed LED:
State Description
Orange 1 Gbps data rate
Green 100 Mbps data rate
Off 10 Mbps data rate
Activity LED:
State Description
Blinking Data transmission or receiving is occurring
On No data transmission or receiving is occurring
