Gigabyte GA-Z68AP-D3 User Manual

Hardware Installation - 10 -
1-2 Product Specications
CPU Support for Intel 
®
Core
™
i7 processors/Intel
®
Core
™
i5 processors/
Intel
®
Core
™
i3 processors/Intel
®
Pentium
®
processors/Intel
®
Celeron
®
processors
in the LGA1155 package
(Go to GIGABYTE's website for the latest CPU support list.)
L3 cache varies with CPU 
Chipset Intel 
®
Z68 Express Chipset
Memory 4 x 1.5V DDR3 DIMM sockets supporting up to 32 GB of system memory 
* Due to Windows 32-bit operating system limitation, when more than 4 GB of physical
memory is installed, the actual memory size displayed will be less than 4 GB.
Dual channel memory architecture 
Support for DDR3 2133/1866/1600/1333/1066 MHz memory modules 
Support for non-ECC memory modules 
SupportforExtremeMemoryProle(XMP)memorymodules 
(Go to GIGABYTE's website for the latest supported memory speeds and memory
modules.)
Onboard
Graphics
Integrated Graphics Processor: 
- 1 x HDMI port, supporting a maximum resolution of 1920x1200
Audio Realtek/VIA HD audio codec 
HighDenitionAudio 
2/4/5.1/7.1-channel 
* Tocongure7.1-channelaudio,youhavetouseanHDfrontpanelaudiomoduleand
enable the multi-channel audio feature through the audio driver.
Support for S/PDIF Out 
LAN 1 x Realtek GbE LAN chip (10/100/1000 Mbit) 
Expansion Slots 1 x PCI Express x16 slot, running at x16 (PCIEX16) 
* For optimum performance, if only one PCI Express graphics card is to be installed,
be sure to install it in the PCIEX16 slot.
1 x PCI Express x16 slot, running at x4 (PCIEX4) 
* The PCIEX4 slot shares bandwidth with the PCIEX1_2 and PCIEX1_3 slots. When
the PCIEX1_2 slot or the PCIEX1_3 slot is populated, the PCIEX4 slot will operate
at up to x1 mode.
3 x PCI Express x1 slots 
(All PCI Express slots conform to PCI Express 2.0 standard.)
2 x PCI slots 
Multi-Graphics
Technology
Support for AMD CrossFireX 
™
technology
* The PCIEX16 slot operates at up to x4 mode when AMD CrossFireX
™
is enabled.

Gigabyte GA-Z68AP-D3 Specifications

General

Non-ECC	Yes
Memory voltage	1.5 V
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR3-SDRAM
Maximum internal memory	32 GB
Supported memory clock speeds	1066, 1333, 1600, 1866, 2133 MHz
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium
USB 2.0 connectors	3
Number of SATA III connectors	2
Number of Parallel ATA connectors	-
USB 3.2 Gen 1 (3.1 Gen 1) connectors	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Parallel ports quantity	1
Motherboard chipset	Intel Z68
Audio output channels	7.1 channels
Motherboard form factor	ATX
Compatible operating systems	Microsoft Windows 7, Vista, XP
Parallel processing technology support	Quad-GPU CrossFireX
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	SATA, SATA II, SATA III
LAN controller	Realtek RTL8111E
Networking features	10/100/1000 Mbps
Ethernet interface type	Fast Ethernet, Gigabit Ethernet
BIOS type	AWARD
ACPI version	1.0b

Weight and Dimensions

Depth	215 mm
Width	305 mm
