Gigabyte GA-Z68AP-D3 User Manual

BIOS Setup - 44 -
Date (mm:dd:yy)
 Setsthesystemdate.Thedateformatisweek(read-only),month,dateandyear.Selectthedesiredeld
and use the up arrow or down arrow key to set the date.
Time (hh:mm:ss)
 Setsthesystemtime.Forexample,1p.m.is13:0:0.Selectthedesiredeldandusetheuparrowordown
arrow key to set the time.
IDE Channel 0, 1 Master/Slave
IDE Channel 0, 1 Master/Slave
 CongureyourSATAdevicesbyusingoneofthethreemethodsbelow:
Auto Lets • the BIOS automatically detect SATA devices during the POST. (Default)
None If no SATA devices are used, set this item to • None so the system will skip the
detection of the device during the POST for faster system startup.
Manual  Allowsyoutomanuallyenterthespecicationsoftheharddrivewhenthehard •
drive access mode is set to CHS.
Access Mode Sets the hard drive access mode. Options are: Auto (default), CHS, LBA, Large.
IDE Channel 2, 3 Master
Extended IDE Drive
 CongureyourSATAdevicesbyusingoneofthetwomethodsbelow:
Auto Lets • the BIOS automatically detect SATA devices during the POST. (Default)
None If no SATA devices are used, set this item to • None so the system will skip the
detection of the device during the POST for faster system startup.
Access Mode Sets the hard drive access mode. Options are: Auto (default), Large.
2-4 Standard CMOS Features
CMOS Setup Utility-Copyright (C) 1984-2011 Award Software
Standard CMOS Features
Date (mm:dd:yy) Thu, Sep 15 2011
Time (hh:mm:ss) 22:31:24

IDE Channel 0 Master [None]

IDE Channel 0 Slave [None]

IDE Channel 1 Master [None]

IDE Channel 1 Slave [None]

IDE Channel 2 Master [None]

IDE Channel 3 Master [None]
Halt On [All, But Keyboard]
Base Memory 640K
Extended Memory 941M
Total Memory 950M
hi
: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level


Gigabyte GA-Z68AP-D3 Specifications

General

Non-ECC	Yes
Memory voltage	1.5 V
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR3-SDRAM
Maximum internal memory	32 GB
Supported memory clock speeds	1066, 1333, 1600, 1866, 2133 MHz
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium
USB 2.0 connectors	3
Number of SATA III connectors	2
Number of Parallel ATA connectors	-
USB 3.2 Gen 1 (3.1 Gen 1) connectors	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Parallel ports quantity	1
Motherboard chipset	Intel Z68
Audio output channels	7.1 channels
Motherboard form factor	ATX
Compatible operating systems	Microsoft Windows 7, Vista, XP
Parallel processing technology support	Quad-GPU CrossFireX
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	SATA, SATA II, SATA III
LAN controller	Realtek RTL8111E
Networking features	10/100/1000 Mbps
Ethernet interface type	Fast Ethernet, Gigabit Ethernet
BIOS type	AWARD
ACPI version	1.0b

Weight and Dimensions

Depth	215 mm
Width	305 mm
