0020239562_02 EASICOM 3 Installation and maintenance instructions 45
J Lengths of the air/flue pipe
Length of the C13 type air/flue pipe
C13 type air/flue pipe
Dia. 60/100 (L) Dia. 80/125 (L)
Length
of
the
air/flue
pipe
EASICOM 3 24c
≤ 9 m ≤ 22 m
EASICOM 3 28c
≤ 9 m ≤ 22 m
Length of the C33 type air/flue pipe
C33 type flue pipe
Dia. 60/100 (L) Dia. 80/125 (L)
Length
of
the
air/flue
pipe
EASICOM 3 24c
≤ 10 m ≤ 25 m
EASICOM 3 28c
≤ 10 m ≤ 25 m
K Technical data
Technical data – Heating
EASICOM 3 24c EASICOM 3 28c
Maximum heating flow temperat-
ure (default setting – D.71)
75 ℃ 75 ℃
Max. range of the flow temperat-
ure regulation
10 … 80 ℃ 10 … 80 ℃
Safety discharge of expansion
relief valve
0.3 MPa
(3.0 bar)
0.3 MPa
(3.0 bar)
Maximum operating pressure
0.25 MPa
(2.50 bar)
0.25 MPa
(2.50 bar)
Nominal water flow (ΔT = 20 K)
870 l/h 1,051 l/h
Nominal water flow (ΔT = 30 K)
580 l/h 700 l/h
Approximate value for the
condensate volume (pH value
between 3.5 and 4.0) at 50/30 °C
2.04 l/h 2.47 l/h
ΔP heating at nominal flow (ΔT =
20 K) – (bypass default setting)
0.025 MPa
(0.250 bar)
0.025 MPa
(0.250 bar)
ΔP heating at nominal flow (ΔT =
20 K) – (bypass closed)
0.043 MPa
(0.430 bar)
0.026 MPa
(0.260 bar)
Technical data – G20 power/loading G20
EASICOM 3 24c EASICOM 3 28c
Maximum heat output (default set-
ting – d.00)
20 kW 24 kW
Effective output range (P) at
50/30 °C
5.3 … 21.2 kW 6.3 … 25.7 kW
Effective output range (P) at
80/60 °C
5.0 … 20.2 kW 6.1 … 24.4 kW
Hot water heat output range (P)
5 … 24.2 kW 6 … 28 kW
Maximum heat input – heating (Q
max.)
20.4 kW 24.7 kW
Minimum heat input – heating (Q
min.)
5.1 kW 6.1 kW
Maximum heat input – hot water
(Q max.)
24.7 kW 28.6 kW
Minimum heat input – hot water (Q
min.)
5.1 kW 6.1 kW
