Shutdown and Cleaning
24 332689D
Cleaning InstaClean™ Fluid
Filter (ProX9 Only)
The InstaClean™ Fluid Filter prevents particles from
entering paint hose. After each use, remove and clean it
to ensure peak performance.
1. Relieve pressure, page 13.
2.
a. Disconnect airless spray hose (a) from sprayer
b. Unscrew outlet fitting (b).
c. Remove InstaClean™ Fluid Filter (c).
3. Check InstaClean™ Fluid Filter (c) for debris. If
needed, clean filter with water and a soft brush.
a. Install closed (square) end of InstaClean™
Fluid Filter (c) in sprayer.
b. Screw outlet fitting (b) into sprayer.
4. Tighten outlet fitting and reconnect hose (a) to
sprayer. Use two wrenches to tighten securely.
Cleaning Gun
• Clean gun fluid filter (d) with water or flushing sol-
vent and a brush every time you flush the system.
Replace gun filter if damaged.
• Remove tip and guard and clean with water or flush-
ing solvent. A soft brush can be used to loosen and
remove dried on material if needed.
• Wipe paint off outside of gun using a soft cloth
moistened with water or flushing solvent.
