Graco ProBell User Manual

Installation
Ground Ground
Ground
the the
the
System System
System
Whenoperatingtheelectrostaticbell,any
ungroundedobjectsinthespraylocation(people,
containers,tools,etc.)canbecomeelectrically
charged.Impropergroundingcanresultinstatic
sparking,whichcancausea󰘰re,explosion,or
electricshock.
Groundallequipment,personnel,objectbeing
sprayed,andconductiveobjectsinorclosetothe
spraylocation.Followthegroundinginstructions
below.
Forfullsystemgroundinginstructionsand
requirements,seeyourapplicatormanual(334452or
334626).Thegroundwirefromtheapplicatormust
beconnectedtothegroundlugontheelectrostatic
controllerorstand.Allcartcomponentsare
connectedtogetherforgrounding.Connectaground
wirefromthegroundinglugontheElectrostatic
Controllerorstandtoatrueearthground.
Figure1GroundonanElectrostaticSystem
Figure2GroundonaNon-ElectrostaticSystem
Complete Complete
Complete
the the
the
Installation Installation
Installation
Ifacompletesystem(Pxxxxx)waspurchased,
linesandcables(except󰘱uid)areconnectedtothe
appropriatecontrolleratthefactory.Tocompletethe
setupandinstallationoftherotaryapplicatorand
system,followtheinstructionsintheProBellRotary
Applicatormanuals.
Connect Connect
Connect
Air Air
Air
Supply Supply
Supply
NOTICE NOTICE
NOTICE
Airthatisnot󰘰lteredtospeci󰘰cationcanclog
bearingairpassagesandcausebearingfailure.
SeetheProBellapplicatormanualfor󰘰lter
requirements.
1.Requiredair󰘰ltershavebeeninstalledonthe
cartatthefactory.
2.Connecttheairsupplytothemainairinleton
youraircontroller.
Note
Onceairisappliedit󰘱owsfreelyoutof
PortBontheSpeedController.
14
3A4232D
