Technical Data

70 311075R

Technical Data

Maximum fluid working

pressure

2000 psi (14 MPa, 140 bar)

Electrical requirements Model AP9570, CS9570: 120 Vac, 1 phase, 50/60 Hz, 3500 W;

requires two separate, dedicated 15 A circuits

Model AP9571, CS9571: 240 Vac, 1 phase, 50/60 Hz, 3800 W;

requires two separate, dedicated 10 A circuits

Model AP9572, CS9572: 240 Vac, 1 phase, 50/60 Hz, 3800 W;

requires a single dedicated 16 A circuit

Model 249806: 120 Vac, 1 phase, 50/60 Hz, 1800 W; requires a sin-

gle dedicated 15 A circuit

Model 249808: 240 Vac, 1 phase, 50/60 Hz, 1800 W; requires a sin-

gle dedicated

8 A circuit

Generator Size (for Reac-

tor E-10 only)

Heated: 5000 W minimum

Nonheated: 2500 W minimum

Maximum Fluid Tempera-

ture

160°F (71°C)

Maximum Ambient Tem-

perature

110°F (43°C)

Maximum Output 12 lb/min (5.4 kg/min) at 340 cycles/min

Output per Cycle (A and

.00352 gal. (.0133 liter)

Overpressure Relief Recirc/Spray valves automatically relieve excessive fluid pressure

back to supply tanks

Heater Power 120V models: 850 W each; 1700 W total

240V models: 1000 W each; 2000 W total

Sound Pressure 78.7 dB(A) in fast circulation mode

84.5 dB(A) at 2000 psi (14 MPa, 140 bar), 0.72 gpm (2.7 lpm)

Sound Power, per ISO

9614-2

88.6 dB(A) in fast circulation mode

94.4 dB(A) at 2000 psi (14 MPa, 140 bar), 0.72 gpm (2.7 lpm)
