Grant SQ2010 User Manual

18108 Version 15 SQ2020/40
Page 17
www.grant.co.uk
7. Connections
NOTE: Blocks G to K as shown above are
only available on 2040 loggers.
As the wiring configuration is dependant upon the sensor type used, it is displayed in SquirrelView
during the setup. Follow the wiring diagram to attach the required sensor. If you would like to print
the diagrams in more detail or view at a later stage select ‘File > Print from Logger Setup’.
The example below shows the actual K type differential thermocouple sensor connected to the 2020
logger from the wiring diagram to the left.
Analogue Inputs
