"Telemetry" menu
SETTING & DATA VIEW
TELEMETRY
SETTING & DATAVIEW
SENSOR
RF STATUS DISPLAY
SELECT ANNOUNCE
RX DATA ON
ALARM SETTING
The basic handling of the "Telemetry" menu is described in the
respective transmitter instructions or the instructions of the Smart-
Box. By way of derogation, only in certain receivers the menu struc-
ture is summarized under the generic term "setting & data view".
These instructions also provide information on how to access this
menu. Change accordingly to the first setting page of the SUMD
Diversity receiver receiver.
Note
The setting values shown in the following display illustrations always
show the standard values.
Receiver display
ALARM VOLT
RECEIVER 1.95
ALARM VOLT: 3.7V
ALARM TEMP: 65°C
PERIOD: 10ms
SENSOR at CH5: Yes
SUMD at CH6: SUMD
RSSI CH : OFF
F.RESET : No
If the receiver voltage falls below the set value, a low-voltage warn-
ing is generated by the transmitter in the form of a "sound-declining
alarm tone" or the "receiver voltage" speech output message.
Adjustment range: 3,5 … 8,0 V
ALARM TEMP
If the receiver temperature exceeds the set temperature, a warning
is generated by the transmitter in the form of a "3-step sound-climb-
ing alarm tone" or the "receiver temperature" speech output mes-
sage.
Adjustment range: 30 … 80 °C
PERIOD
Determines the time interval of the impulse transmission.
Adjustment range: 10 or 20 ms
Note
Changing the cycle time is only necessary when installing analogical
servos for additional functions.

GRAUPNER GR-12L Specifications

General

Type	Radio-Controlled (RC) Model Parts
Proper use	Helicopter
Product type	Receiver
Programmable	Yes
Product color	Black, Green
Frequency range	2400 - 2483.5 MHz
Channels quantity	16 channels
Brand compatibility	Graupner
Maximum operating distance	3000 m
Voltage	3.6-8.4 V
Operating temperature (T-T)	-15 - 70 °C

Weight and Dimensions

Width	25 mm
Height	4 mm
Weight	4 g
