RX FREE MIXER
Up to five mixers can be contemporaneously programmed. The fol-
lowing settings in this display only relate to the mixers 1 ... 5 selected
in the "MIXER" line.
As long as the value fields of the lines "MASTER CH" and "SLAVE CH"
are set to "0", no mixer is active.
Value Description Possible settings
MIXER Mixer selection 1 … 5
MASTER CH Signal source or source
channel
0, 1 … according to the
receiver
SLAVE CH Target channel 0, 1 … depending on the
receiver
TRIM Trim ±30 %
TRAVEL– Mixing on the "–" side
of the servo travel in
percentage servo
travel
0 … 100 %
TRAVEL+ Mixing on the "+" side
of the servo travel in
percentage servo
travel
0 … 100 %
CH REVERSE
This sets the direction of rotation of the servo connected to the
selected control channel:
Adjustment range: Normal/ Reverse
RX FREE MIXER
MASTER CH: 0
SLAVE CH: 0
TRAVEL–: 100%
TRAVEL+: 100%
MIXER: 1
TRIM: 0%
CH REVERSE
CH2: Normal
CH3: Normal
CH5: Normal
CH6: Normal
CH1: Normal
CH4: Normal

GRAUPNER GR-12L Specifications

General

Type	Radio-Controlled (RC) Model Parts
Proper use	Helicopter
Product type	Receiver
Programmable	Yes
Product color	Black, Green
Frequency range	2400 - 2483.5 MHz
Channels quantity	16 channels
Brand compatibility	Graupner
Maximum operating distance	3000 m
Voltage	3.6-8.4 V
Operating temperature (T-T)	-15 - 70 °C

Weight and Dimensions

Width	25 mm
Height	4 mm
Weight	4 g
