GRAUPNER GR-12L User Manual

3 / 24
16570.123_V1sh
Index
Introduction ......................................................................................4
Service centre ...................................................................................4
Intended use ....................................................................................5
Target group ....................................................................................5
Package content ................................................................................5
Technical data ...................................................................................6
Symbol description ...........................................................................6
Safety notes ......................................................................................6
For your safety by handling the transmitter and the receiver .......7
For your safety by handling the batteries ......................................8
Installation of the SUMD Diversity receiver ...................................8
Connection points of the circuit board ...........................................9
Binding .............................................................................................15
Video transmitter 16570.123 .........................................................16
"Telemetry" menu ..........................................................................17
SETTING & DATA VIEW ..................................................................17
Receiver display .........................................................................17
RX FREE MIXER ...........................................................................19
CH REVERSE ................................................................................19
SIMPLIFIED DECLARATION OF CONFORMITY ................................22
Manufacturer ................................................................................22
Notes on environmental protection ..............................................23
Care and maintenance ...................................................................23
Warranty conditions .......................................................................23

GRAUPNER GR-12L Specifications

General

Type	Radio-Controlled (RC) Model Parts
Proper use	Helicopter
Product type	Receiver
Programmable	Yes
Product color	Black, Green
Frequency range	2400 - 2483.5 MHz
Channels quantity	16 channels
Brand compatibility	Graupner
Maximum operating distance	3000 m
Voltage	3.6-8.4 V
Operating temperature (T-T)	-15 - 70 °C

Weight and Dimensions

Width	25 mm
Height	4 mm
Weight	4 g
