Unit Installation
salty fog and polluted air.
1.2 Matters Need Attention
(1) The installation of unit must be in accordance with national and local safety codes.
(2) Installation quality will directly affect the normal use of air conditioner unit. The user is prohibited from
installation by himself. Please contact your dealer after buying this machine. Professional installation workers
will provide installation and test services according to installation manual.
(3) Do not connect to power until all installation work is completed.
2 Filed Supplied Pipes and Valves
Name Picture
Usage
Water Filter
It is used to remove foreign matters in the
waterway.
2-way Valve
It is used to switch waterways between underoor
system and the FCU.
3-way Valve
It is used to switch waterways of hot water inside
the water tank and circulation water inside the main
unit.
Bypass Valve
It is used to balance the water pressure.
Water Trap
It is used to distribute water.
Pipe Joint
It is used to connect the water pipes.
Cut-off Valve
It is used to cut off or get through the waterway.
To Next Page
